✦Power Amplifiers

GZ023-A

Manufacturer
797 Audio
Model
A031U5
Code
GW-LVNZMA
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

10
Power
power_w
2 x 400 (8 ohm) / 2 x 500 (4 ohm)W
1
Power W Bridged
power_w_bridged
1000 (8 ohm, bridged mono)W
1
Frequency range
frequency_range_hz
20 - 20000 (+/-0.5 dB)Hz
1
THD
thd
<= 0.5%
1
SNR
snr_db
>= 94dB
1
Damping factor
damping_factor
> 70 (1 kHz)
1
Input Sensitivity
input_sensitivity
4dBV
1
Input impedance
input_impedance_ohm
>= 10000Ohm
1
Weight
weight_kg
20.5kg
1
Dimensions
dimensions
480 x 400 x 110 (W x D x H)mm
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
