✦Line Arrays

CS10

Manufacturer
Adamson
Model
CS10
Code
GW-MMYNVM
Data status
Level 1 / 5
AI-parsed

❋ Specs

9
Frequency range
frequency_range_hz
60 - 18000Hz
1
Max SPL
max_spl_db
141.3dB
1
Weight
weight_kg
31kg
1
Dimensions
dimensions
265/178 (H front/back) x 737 (W) x 526 (D)mm
1
Drivers
drivers
2x ND10-LM 10" Kevlar Neodymium LF drivers + Adamson NH4 4" diaphragm / 1.5" exit HF compression driver
1
Amplifier
amplifier
2-channel Class-D
1
Power
power_w
2400W
1
Configuration
configuration
two-way, nominal directivity 110 x 10 (H x V)degrees
1
Amplification
amplification
Self-powered (built-in amplifier)
1
