✦Line Arrays

CS7

Manufacturer
Adamson
Model
CS7
Code
GW-P6AQFG
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Configuration
configuration
2-way, full-range powered line array
1
Drivers
drivers
2x ND7-LM16 7" Kevlar Neodymium LF + NH3 3" diaphragm / 1.4" exit HF compression driver
1
Frequency range
frequency_range_hz
80-18000 (±3 dB)Hz
1
Dispersion
dispersion_deg
100 x 12.5 (H x V, -6 dB)deg
1
Max SPL
max_spl_db
138dB
1
Amplifier
amplifier
2-channel Class-D, onboard
1
Power
power_w
2400W
1
Weight
weight_kg
17.5kg
1
Dimensions
dimensions
527 (W) x 203 front / 122 back (H) x 411 (D)mm
1
Rigging
rigging
Slidelock Rigging System
1
Network
network
Milan (redundant), 2x etherCON, analog XLR in/through
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
