VPX-RX1-SDM

Manufacturer
Aurora Multimedia
Model
VPX-RX1-SDM
Code
GW-PMFHDR
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Max resolution
max_resolution
4K60 4:4:4 UHD decoder
1
Bandwidth Gbps
bandwidth_gbps
1Gbps
1
Form factor
form_factor
Intel SDM slot card
1
Codec Compression
codec_compression
Mimix
1
Latency
latency_ms
Zero frame (1.78ms)
1
Color Depth
color_depth
12-bit color, 16-bit OSD
1
Hdcp
hdcp
2.2
1
Hdr
hdr
HDR10, HDR10+, Dolby Vision
1
Audio
audio
LPCM up to 12ch, Dolby TrueHD, DTS-HD MA, ATMOS; Dante 2ch opt
1
Networking
networking
1G LAN PoE + SFP (Fiber or 2nd RJ-45)
1
USB
usb
USB 2.0 (cameras, HID, mass storage)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
