✦Video & Media

DE20-4K

Manufacturer
AVMatrix
Model
DE20-4K
Code
GW-LFN3YS
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Hdmi Input
hdmi_input
1x (up to 2160p60)
1
Hdmi Loop Output
hdmi_loop_output
1x (up to 2160p60, zero-latency)
1
Hdmi Decode Output
hdmi_decode_output
1x (up to 2160p30)
1
Encode Formats
encode_formats
2160p30/25/24, 1080p60/50/30/25/24, 1080i, 720p
1
Streaming protocols
streaming_protocols
RTSP/RTMP/RTMPS/SRT/NDI (NDI|HX/HX2/HX3 optional)
1
Max Bitrate Mbps
max_bitrate_mbps
50Mbps
1
Network
network
1xLAN with PoE+ (802.3at)
1
USB
usb
1xUSB Type-A (UVC capture + recording/camera)
1
Recording
recording
SD card / USB / NAS (FAT32/exFAT), up to 4K30
1
Dc Input
dc_input_v
6-20 (or PoE)V
1
Power
power_w
8W
1
Dimensions
dimensions
104x125.5x24.5mm
1
Weight
weight_g
501g
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
