✦System Processors

TA6000-R

Manufacturer
Bag End Loudspeakers
Model
TA6000-R
Code
GW-WBEWES
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

11
Configuration
configuration
compact 2-way trapezoidal Time-Align full-range loudspeaker (road/portable version)
1
LF driver
lf_driver_in
6.5in (2 x cone, 1.5" voice coil, 30 oz magnet)
1
HF driver
hf_driver
1" exit compression driver, 1.8" titanium diaphragm on radial horn
1
Peak power handling
power_handling_peak_w
600W (peak)
1
Frequency range
frequency_range_hz
85-18000Hz
1
Sensitivity
sensitivity_db
95dB SPL (1W @ 1m)
1
Max SPL
max_spl_db
127dB (above 200 Hz @ 1 m)
1
Dispersion
dispersion_deg
80 H x 60 Vdeg
1
Crossover frequency
crossover_frequency_hz
2100Hz
1
Enclosure
enclosure
15 mm 11-ply birch plywood
1
Dimensions
dimensions
approx. 23"h x 9"w x 11"d (trapezoidal)in
1
