✦Audio

S16

Manufacturer
Behringer
Model
S16
Code
GW-EG4ABZ
Data status
Level 1 / 5
AI-parsed

❋ Specs

17
Mic inputs
mic_inputs
16 (Midas-designed programmable preamps)ch
1
Line Outputs
line_outputs
8 (servo-balanced XLR)ch
1
Sample rate
sample_rate_khz
44.1 / 48kHz
1
Connectivity
connectivity
2x AES50 (Klark Teknik SuperMAC), 2x ADAT, ULTRANET (P-16), MIDI I/O, USB; up to 100 m Cat5e
1
Ad Dynamic Range Db
ad_dynamic_range_db
109dB
1
Da Dynamic Range Db
da_dynamic_range_db
108dB
1
Frequency range
frequency_range_hz
10-22000Hz
1
Power
power_w
45W
1
Dimensions Wxdxh
dimensions_wxdxh_mm
482 x 225 x 89mm
1
Weight
weight_kg
4.7kg
1
Rack units
rack_units_u
2U
1
Channels
channels
16
1
Connectors
connectors
XLR, AES50 x2, ADAT x2, ULTRANET, USB, MIDI
1
Dimensions
dimensions_mm
482x225x89mm
1
Inputs
inputs
16
1
Outputs
outputs
8
1
Phantom power
phantom_power_v
48V
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
