✦Cameras

R9-420N

Manufacturer
Bolin Technology
Model
9106E005
Code
GW-3PM6CV
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

16
Sensor type
sensor_type
Sony IMX715 CMOS, 1/2.8 inch
1
Effective pixels
effective_pixels_mp
8.29MP
1
Video resolution
video_resolution
3840x2160 (4K)
1
Max frame rate
max_frame_rate_fps
60fps
1
Optical zoom
optical_zoom_x
20x
1
Focal length
focal_length_mm
3.55-71mm
1
Aperture Fnumber
aperture_fnumber
F2.0-F3.8
1
Horizontal FOV
horizontal_fov_deg
78.59-4.92deg
1
Min illumination
min_illumination_lux
0.5 (color), 0.1 (B&W)lux
1
Pan range
pan_range_deg
340deg
1
Tilt range
tilt_range_deg
120deg
1
Video outputs
video_outputs
HDMI 2.0, dual 12G-SDI, optical SDI, NDI HX3/High Bandwidth, IP (RTMP/RTSP/SRT)
1
Power
power_w
51-57W
1
Input voltage
input_voltage
DC12V / PoE++ (802.3bt)
1
Dimensions
dimensions
201x253x249 (WxDxH)mm
1
Weight
weight_kg
3.8kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
