✦Audio

AR-133

Manufacturer
BSS Audio
Model
AR-133
Code
GW-YZHCIG
Data status
Level 1 / 5
AI-parsed

❋ Specs

16
Type
type
active DI box / line balancer
1
Frequency range
frequency_range_hz
30-20000 (+0/-1dB)Hz
1
Input impedance
input_impedance_ohm
1000000 (0dB pad) / 47000 (-20/-40dB pad)ohm
1
Max Input Dbu
max_input_dbu
+9 (0dB) / +29 (-20dB) / +49 (-40dB)dBu
1
Max Output Dbu
max_output_dbu
+8 (into 600 ohm or greater)dBu
1
THD
thd
<0.005 (1kHz, 0dBu out)%
1
Noise
noise_db
<-105 (unweighted, 22Hz-22kHz)dB
1
Pad
pad_db
0 / -20 / -40dB
1
Connectors
connectors
1/4" jack + XLR in, 1/4" link, XLR out
1
Dimensions
dimensions
59 x 124 x 143 mm
1
Weight
weight_kg
0.65 (excl. battery)kg
1
Power
power_w
+48V to +20V phantom or 9V PP3 battery
1
Dimensions
dimensions_mm
59 x 124 x 143mm
1
Impedance
impedance_ohm
1000000 / 47000Ω (0dB / -20дБ-40дБ пад)
1
Phantom power
phantom_power_v
20-48VDC
1
THD
thd
<0.005% (1kHz, 0dBu)
1
