✦Audio

FDS-336T

Manufacturer
BSS Audio
Model
FDS-336T
Code
GW-NZZVRV
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Inputs
inputs
2каналов
1
Outputs
outputs
6каналов
1
Impedance
impedance_ohm
10000Ω (вход)
1
Frequency range
frequency_range_hz
15-20000Hz (±0.25dB)
1
THD
thd
<0.01% (20Hz-20kHz, +10dBu)
1
Dynamic range
dynamic_range_db
>108dB (unweighted, 22Hz-22kHz)
1
Max Delay Ms
max_delay_ms
635ms
1
EQ bands
eq_bands
38полос EQ
1
Crossover Slopes
crossover_slopes
Bessel 12-24; Linkwitz-Riley 12-24-48; Butterworth 6-48; WHISEworks-NTM 36-52dB/octave
1
Dimensions
dimensions_mm
44.4 x 483 x 203mm (В x Ш x Г)
1
Weight
weight_kg
2.8kg
1
Power
power_w
30VA
1
