✦Lighting

AirLED Driver 6Ch

Manufacturer
Bytecraft Entertainment
Model
801-272-23
Code
GW-OCKPEY
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
DMX channels
dmx_channels
6 constant-current outputs (1-6 ch variants 801-272-18..23)ch
1
Output Current Ma
output_current_ma
350 to 1500 per channel (options)mA
1
Dc Supply
dc_supply_v
7-48 (0.5A-3.0A per channel)V
1
Control Inputs
control_inputs
DMX512, 0-10V analogue, dry-contact ON/OFF, RDM (option)
1
Control Technique
control_technique
AIR Adaptive Variable Power Control, 14-bit adaptive resolution
1
Signal Frequency Hz
signal_frequency_hz
200-900 (variable PWM)Hz
1
Efficiency
efficiency
0.977
1
Led Support
led_support
individual, dual-white, RGB, RGBWA fixtures
1
Dimensions
dimensions
44 x 87 x 228mm
1
Weight
weight_g
950g
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
