✦Lighting

Wincon 6 Linear Controller

Manufacturer
Bytecraft Entertainment
Model
811-156-00
Code
GW-IUCGDR
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Axes
axes
1 axis per Wincon; up to 10 Wincons in a 6U 19" sub-rack
1
Control Type
control_type
accurate closed-loop variable-speed supervision, kilograms to tonnes lifting capacity
1
Safety
safety
HSI (High Safety Integrity) - redundant safety-supervisor microprocessor, solid-state safety logic
1
Networks
networks
Ethernet 10/100-Base-T, Profibus-DP option, 2x RS-485 serial
1
Drive Support
drive_support
any drive type - AC, DC or hydraulic energy sources
1
Encoders
encoders
absolute and incremental encoders supported
1
Performance
performance
at least 10x performance vs Wincon III
1
Monitoring
monitoring
torque & load-cell weighing, position/velocity/acceleration limits, snag/overshoot detection, emergency stop
1
Board Dimensions
board_dimensions
board H233 x D160; front panel H260 x W40mm
1
Weight
weight_g
350g
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
