✦Line Arrays

C10-i

Manufacturer
Clair Brothers
Model
C10-i
Code
GW-G9PBL3
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

8
Configuration
configuration
Active 3-Way line array element, TrueFit
1
Frequency range
frequency_range_hz
50-20000Hz
1
Max SPL
max_spl_db
146dB
1
Drivers
drivers
LF (2) 10 in; MF (1) 3.5 in; HF (1) 1.4 in exit
1
Power Handling Lf
power_handling_lf_w
3200W
1
Nominal impedance
nominal_impedance_ohm
16 (LF/MF/HF)ohm
1
Dispersion H Deg
dispersion_h_deg
70-120 (10 deg increments)deg
1
Dispersion V Deg
dispersion_v_deg
15deg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
