✦Staging & Structures

NH D8+ Entertainment

Manufacturer
CM Lodestar
Model
D8+ Model L (1000 kg)
Code
GW-TSEY5Z
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Rated Capacity
rated_capacity_kg
1000kg
1
Lifting speed
lifting_speed_m_min
4m/min
1
Capacity range
capacity_range_kg
125-2000kg
1
Weight
weight_kg
75kg
1
Load Chain Size
load_chain_size_mm
7.9 x 21.7mm
1
Design Factor
design_factor
10:1 (with double brake)
1
Fem Class
fem_class
2M
1
Duty Rating
duty_rating
H4 (30 min / 300 starts per hour)
1
Brake Config
brake_config
double brake (redundant)
1
Safety Standard
safety_standard
D8+ / IGVW SQ P2 / SR2.0 / VPLT (TUV SUD certified)
1
Standard lift
standard_lift_m
18 (25/40 optional)m
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
