✦Staging & Structures

Small Frame (Next Gen NH)

Manufacturer
CM Lodestar
Model
Model F (500 kg, 4 m/min)
Code
GW-LEG09O
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

12
Rated Capacity
rated_capacity_kg
500kg
1
Lifting speed
lifting_speed_m_min
4m/min
1
Capacity range
capacity_range_kg
125-500kg
1
Motor Power Hp
motor_power_hp
0.5HP
1
Weight Per Metre
weight_per_metre_kg
1.2kg/m
1
Load Chain Size
load_chain_size_mm
6.3 x 18.9mm
1
Reeves Falls Of Chain
reeves_falls_of_chain
1
1
Power Consumption
power_consumption_a
1.2A
1
Operating Voltage
operating_voltage
400-3-50V/ph/Hz
1
Fem Class
fem_class
2M (40% duty cycle)
1
Noise level
noise_level_db
68dB(A)
1
Standard lift
standard_lift_m
18m
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
