✦Audio

Type 10 Direct Box

Manufacturer
Countryman Associates
Model
DT10
Code
GW-GLDJYK
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Type
type
active direct box
1
Frequency range
frequency_range_hz
10-50000 (+/-1 dB)Hz
1
Input Impedance Mohm
input_impedance_mohm
10 (0 dB pad); 10k Ohm (-15/-30 dB pad)MOhm
1
Pad
pad_db
0 / -15 / -30dB
1
Thd Distortion Pct
thd_distortion_pct
<0.001 (at 1kHz)%
1
Noise Uvrms
noise_uvrms
1.8 (-115 dBVrms)uVrms
1
Input Capacitance Pf
input_capacitance_pf
240pF
1
Phantom power
phantom_power_v
48 (1.5 mA)V
1
Battery life
battery_life_h
130 (9V alkaline)h
1
Dimensions
dimensions
45 x 77 x 152mm
1
Weight
weight_kg
0.59kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
