✦System Processors

SH-69

Manufacturer
Danley Sound Labs
Model
SH69
Code
GW-IIX82N
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Coverage pattern
coverage_pattern_deg
60 x 90deg
1
Frequency range
frequency_range_hz
55-18000 (+/-3 dB); 33-24000 (-10 dB)Hz
1
Sensitivity
sensitivity_db
99dB SPL
1
Continuous SPL
max_spl_continuous_db
126dB SPL
1
Peak SPL
max_spl_peak_db
132dB SPL
1
Continuous power
power_continuous_w
1000W
1
Peak power
power_peak_w
4000W
1
Impedance
impedance_ohm
4ohm
1
Drivers
drivers
2x 12in LF, 6x 4in MF, 1x 1in HF
1
Dimensions
dimensions_in
34 x 21 x 17 (H x W x D)in
1
Weight
weight_kg
52.6kg
1
Weight
weight_lbs
116lbs
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
