✦Line Arrays

VIO L210

Manufacturer
dBTechnologies
Model
1030102421
Code
GW-WDTHFF
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Configuration
configuration
2-way active line array module, bi-amped
1
LF driver
lf_driver
2x 10" neodymium, 2.5" voice coil
1
HF driver
hf_driver
1x 1.4" exit, 3" voice coil neodymium
1
Power
power_w
900W RMS
1
Max SPL
max_spl_db
135dB
1
Frequency range
frequency_range_hz
67-20000Hz (-6 dB)
1
Horizontal coverage
horizontal_coverage_deg
100deg
1
Weight
weight_kg
28.6kg
1
Dimensions
dimensions
720 x 320 x 520mm (W x H x D)
1
Amplifier
amplifier
Class-D Digipro G3
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
