✦Power Distros

125A 3PH Type3-1

Manufacturer
Distro Design
Model
00942
Code
GW-WEDUPW
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Input current
input_current_a
125A
1
Input Phase
input_phase
3PH+N+E (three phase)
1
Input voltage
input_voltage_v
415V
1
Input Protection
input_protection
125A C-type 4P MCB, IP67 inlet
1
Outputs 63A Count
outputs_63a_count
1x 63A 415V 3PH IP67 (63A C-type 4P MCB)
1
Outputs 32A 3Ph Count
outputs_32a_3ph_count
3x 32A 415V 3PH IP44 (32A C-type 4P MCB)
1
Outputs 32A 1Ph Count
outputs_32a_1ph_count
6x 32A 240V 1PH IP44 (32A 2P 30mA RCBO)
1
Outputs 16A Count
outputs_16a_count
12x 16A 240V 1PH IP44 (16A 2P 30mA RCBO)
1
Housing material
housing_material
HDPE (high density polyethylene)
1
Dimensions
dimensions
575 x 420 x 690 (L x D x H, incl. feet)mm
1
Weight
weight_kg
33kg
1
Standards
standards
BS EN 61439-1 & 4, BS EN 7909, BS EN 61557-6; CE/UKCA
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
