✦Power Distros

32A 3PH Square 1

Manufacturer
Distro Design
Model
00930
Code
GW-RBRCTM
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Input current
input_current_a
32A
1
Input Phase
input_phase
3PH+N+E (three phase)
1
Input voltage
input_voltage_v
415V
1
Output Link Out
output_link_out
1x 32A 415V 3PH+N+E IP44 panel socket link out
1
Outputs 16A Count
outputs_16a_count
6x 16A 240V 1PH IP44 panel socket
1
Protection
protection
6x 16A 2P 30mA RCBO
1
Housing material
housing_material
HDPE (high density polyethylene)
1
Dimensions
dimensions
430 x 410 x 180 (L x D x H, incl. feet)mm
1
Weight
weight_kg
8kg
1
Standards
standards
BS EN 61439-1 & 4, BS EN 7909, BS EN 61557-6; CE/UKCA
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
