✦Line Arrays

Anya

Manufacturer
Eastern Acoustic Works
Model
Anya
Code
GW-DXOYQ2
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Configuration
configuration
ADAPTive self-powered 3-way line source module
1
Drivers
drivers
2x 15" LF (4" VC), 6x 5" MF (38mm VC), 14x 1" HF (35mm VC)
1
Frequency range
frequency_range_hz
35 - 18000Hz
1
Max SPL
max_spl_db
152dB
1
Horizontal coverage
horizontal_coverage_deg
70 (single column, scalable to 360)deg
1
Vertical coverage
vertical_coverage_deg
Adaptive (electronically steerable)
1
Amplifier power
amplifier_power_w
2x 1700 (LF) + 6x 350 (MF) + 14x 350 (HF)W
1
DSP
dsp
22 channels of onboard DSP, Resolution 2 control
1
Input connectors
input_connectors
powerCON TRUE1, Analog & AES In/Loop, 2x etherCON (Dante)
1
Weight
weight_kg
129.3kg
1
Dimensions
dimensions
434 x 1148 x 762 (H x W x D)mm
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
