✦Lighting

DMX USB Pro

Manufacturer
Enttec
Model
70304
Code
GW-DHA6NN
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
DMX universes
dmx_universes
1
1
DMX channels
dmx_channels
512
1
Refresh Rate Fps
refresh_rate_fps
40fps
1
Isolation
isolation_v
1500V
1
Connectors
connectors
1x DMX out (XLR5 female), 1x DMX in (XLR5 male), 1x USB 2.0 Type-B
1
Input voltage
input_voltage_v
5V DC (via USB)
1
Input Current Ma
input_current_ma
300mA
1
Power
power_w
1.5W
1
Weight
weight_kg
0.08kg
1
Dimensions
dimensions
80 x 58 x 40mm
1
Operating temperature
operating_temperature_c
0 to 50C
1
Protocol
protocol
USITT DMX512-A, ANSI E1.20 RDM
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
