EXT-DP-4K600-1SC

Manufacturer
Gefen
Model
EXT-DP-4K600-1SC
Code
GW-WMLBGI
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Video Bandwidth Gbps
video_bandwidth_gbps
21.6 (5.4/lane x 4 lanes)Gbps
1
Frequency Mhz
frequency_mhz
600MHz
1
Max resolution
max_resolution
4096x2160@60Hz 4:4:4 (4K DCI)
1
Displayport Version
displayport_version
1.2
1
Extension Distance
extension_distance_m
200m
1
Fiber Type
fiber_type
SC-terminated OM3/OM4 (50/125um) multimode
1
HDCP version
hdcp_version
2.2 / 1.4 / DPCP
1
Power supply voltage
power_supply_v
5V DC
1
Power
power_w
3.75 (1.75 Tx + 2.0 Rx)W
1
Dimensions
dimensions
45 x 22 x 79 (per unit)mm
1
Weight
weight_kg
0.135kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
