✦Video Mixers / Scalers

EXT-UHD600A-12-DS

Manufacturer
Gefen
Model
EXT-UHD600A-12-DS
Code
GW-MFJZNG
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Inputs
inputs
1HDMI
1
Outputs
outputs
2HDMI
1
Video Bandwidth Gbps
video_bandwidth_gbps
18.2Gbps
1
Tmds Clock Mhz
tmds_clock_mhz
600MHz
1
Max resolution
max_resolution
4096x2160@60Hz 4:4:4 (passthrough) / 3840x2160@60Hz (scaled)
1
HDMI version
hdmi_version
2.0
1
HDCP version
hdcp_version
2.2 / 1.4
1
Audio channels
audio_channels
8 (HBR passthrough)ch
1
Audio Deembed Outputs
audio_deembed_outputs
TOSLINK (5.1) + 3.5mm stereo
1
Power supply voltage
power_supply_v
5V DC
1
Power
power_w
4W
1
Dimensions
dimensions
94 x 25 x 82mm
1
Weight
weight_kg
0.14kg
1
