HDK-X500

Manufacturer
Ikegami
Model
HDK-X500
Code
GW-HUTKC0
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Sensor type
sensor_type
2/3-inch 3-CMOS with global shutter, R/G/B prism
1
Resolution
resolution
1920 x 1080px
1
Sensitivity F
sensitivity_f
F11 (1080i/59.94) / F12 (1080i/50)F
1
Signal-to-noise ratio
signal_to_noise_db
62dB
1
Horizontal Resolution Tvl
horizontal_resolution_tvl
1000TVL
1
Weight
weight_kg
5kg
1
Dimensions
dimensions
148.5 x 243 x 340mm
1
Lens mount
lens_mount
B4 bayonet
1
Input voltage
input_voltage_v
11 to 17V
1
Frame Rates Hz
frame_rates_hz
1080p 59.94/50, 1080i 59.94/50, 720p 59.94/50Hz
1
