✦System Processors

GRAVIS 12+ N

Manufacturer
Kling & Freitag
Model
GRAVIS 12+ N
Code
GW-VRO1JH
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Type
type
passive 2-way bass-reflex system, rotatable horn
1
Frequency range
frequency_range_hz
65-23000Hz
1
Max SPL
max_spl_db
134dB
1
Weight
weight_kg
17.8kg
1
Dimensions
dimensions
350 x 596 x 318mm
1
Drivers
drivers
12" low-mid chassis, 1.4" compression driver (75 mm titanium)
1
Horizontal coverage
horizontal_coverage_deg
65deg
1
Vertical coverage
vertical_coverage_deg
50deg
1
Power
power_w
400 nominal / 800 program / 1600 peakW
1
Impedance
impedance_ohm
8ohm
1
Connectors
connectors
2 x speakON 4-pol NLT4MP (IN parallel to OUT)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
