✦Lighting

Burstberry

Manufacturer
Kvant
Model
Burstberry
Code
GW-3MXV3O
Data status
Level 1 / 5
AI-parsed
No photo yet

❋ Specs

15
Power
power_w
2W
1
Wavelength
wavelength_nm
637/520/445 (R/G/B)nm
1
Scan speed
scan_speed_kpps
28 @ 8°kpps
1
Scanning Angle Deg
scanning_angle_deg
60deg
1
Beam divergence
beam_divergence_mrad
0.58mrad
1
Weight
weight_kg
3.8kg
1
Dimensions
dimensions_mm
171x171x359 (WxHxD)mm
1
Power consumption
power_consumption_va
340VA
1
Connectors
connectors
Neutrik powerCON TRUE1
1
Inputs
inputs
Ethernet, ArtNet (FB4-STD controller)
1
Outputs
outputs
3 W LED blanker (warm white) + interchangeable diffraction grating (burst effect); modular cluster docking in 12 directions
1
Colours
colours
RGB (full-colour)
ILDA
ilda
Yes (ILDA in/out, Ethernet, ArtNet, DMX via FB4-SK)
Laser power
laser_power_mw
2000mW
Safety class
safety_class
Class 4 (EN 60825-1, TUV SUD tested, FDA)

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
