✦Line Arrays

ARCS II

Manufacturer
L-Acoustics
Model
ARCS II
Code
GW-9WE34W
Data status
Level 1 / 5
AI-parsed
Verified vendor

❋ Specs

14
Configuration
configuration
2-way active
1
Frequency range
frequency_range_hz
50 - 20000Hz
1
Max SPL
max_spl_db
142dB
1
Dispersion
dispersion_deg
22.5 symmetric x 60 asymmetric (-20/+40)degrees
1
Drivers
drivers
LF: 1 x 15" neodymium, weather-resistant, bass-reflex; HF: 1 x 3" neodymium diaphragm compression driver, DOSC waveguide
1
Nominal impedance
nominal_impedance_ohm
LF: 8; HF: 8ohm
1
Power
power_w
LF: 600; HF: 100 (RMS power handling)W
1
Amplifier
amplifier
LA4X or LA8 controller
1
Connectors
connectors
IN: 1 x 4-point speakON; LINK: 1 x 4-point speakON
1
Dimensions
dimensions
439 x 820 x 652 (WxHxD)mm
1
Weight
weight_kg
50kg
1
Cabinet
cabinet
Baltic birch plywood
1
Protection rating
protection_rating
IP55
1
Recommended amplifier
recommended_amplifier
L-Acoustics LA4X / LA8 (bi-amp; also LA12X)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
LA4XGW-5KKEQFLA8GW-Q8FP0ELA12XGW-3TZURY

L-Acoustics LA4X / LA8 (bi-amp; also LA12X)
