✦Audio

DBu

Manufacturer
Lectrosonics
Model
DBu
Code
GW-CD2SCR
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Type
type
Digital bodypack transmitter
1
Frequency range
frequency_range_mhz
470-608 (470-614 export)MHz
1
RF output power
rf_output_power_mw
25 / 50mW
1
Audio resolution
audio_resolution
24-bit / 48 kHz
1
Audio Frequency Response Hz
audio_frequency_response_hz
20-20000 (+0/-3 dB)Hz
1
Dynamic range
dynamic_range_db
110 (before limiting)dB
1
Encryption
encryption
AES-256-CTR
1
Battery type
battery_type
2 x AA
1
Battery life
battery_life_h
approx. 5h
1
Connector
connector
TA5 (DBu) / LEMO (DBu-LEMO)
1
