✦Audio

DSQD

Manufacturer
Lectrosonics
Model
DSQD
Code
GW-J36HWE
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Type
type
4-channel digital wireless receiver (half-rack)
1
DMX channels
dmx_channels
4
1
Frequency range
frequency_range_mhz
470.100-614.375MHz
1
Tuning Step Khz
tuning_step_khz
25kHz
1
Audio resolution
audio_resolution
24-bit / 48 kHz
1
Modulation
modulation
8PSK with Forward Error Correction
1
Encryption
encryption
AES-256-CTR (FIPS 197 / FIPS 140-2)
1
Latency
latency_ms
1.0 (digital source) + Dante networkms
1
Sensitivity Dbm
sensitivity_dbm
-98 (for 1e-5 BER)dBm
1
Outputs
outputs
Analog & digital XLR, Dante (Ethernet)
1
Dimensions
dimensions
212.7 x 44.5 x 187.3 (8.375 x 1.75 x 7.375 in)mm
1
Weight
weight_g
880 (1.95 lbs)g
1
Channels
channels
4
1
Connectors
connectors
4x XLR analog out, Dante/Ethernet (RJ45), USB, 2x BNC antenna + loop-thru, IR port
1
Dimensions
dimensions_mm
213x44.5x187mm
1
Frequency range
frequency_range_hz
470100000-614375000Hz
1
Rated current
rated_current_a
2.5A
1
Weight
weight_kg
0.88kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
