Power

LCP

Manufacturer
LynTec
Model
LCP 378
Code
GW-X8U65F
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Circuit Positions
circuit_positions
30 / 42 / 48 / 66 / 84
1
Main Breaker
main_breaker_a
100 / 125 / 150 / 175 / 200 / 225 / 400
1
Breaker Rating
breaker_rating_a
15 / 20 / 30
1
Breaker Poles
breaker_poles
1 / 2 / 3
1
Control Zones
control_zones
12
1
Dmx Address Sets
dmx_address_sets
4 (DMX-512 / sACN)
1
Control protocols
control_protocols
DMX-512, sACN, TCP/IP, RS-232, BACnet, Telnet, HTTP, contact closure
1
Scheduling Events
scheduling_events
84 (incl. sunrise/sunset)
1
Breaker Cycle Rating
breaker_cycle_rating
200000cycles
1
Breaker Mtbf
breaker_mtbf
900000cycles
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
