✦PAR / LED / Profile

NEBULA

Manufacturer
Madrix
Model
NEBULA
Code
GW-9LWWAX
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Spi Outputs
spi_outputs
12 (firmware >= 6.00; 8 previously)port
1
Max Rgb Pixels Per Port
max_rgb_pixels_per_port
1020pixel
1
Supported Ics
supported_ics
over 70 (WS2812B, WS2815, SK6812, APA102...)
1
Input Protocols
input_protocols
Art-Net (I/II/3/4, ArtSync), sACN (E1.31), USB
1
Connectors
connectors
2x 4-pin pluggable screw terminals (SPI out)
1
Ethernet ports
ethernet_ports
2x RJ45
1
Power supply voltage
power_supply_v
5-24 (DC)V
1
Power
power_w
1.5W
1
Dimensions
dimensions
90 x 70 x 46mm
1
Weight
weight_kg
0.110kg
1
Operating temperature
operating_temperature_c
-10 to 70degC
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
