✦Moving Head (Spot/Wash/Beam)

MAC Viper XIP

Manufacturer
Martin
Model
90758000
Code
GW-HHPEPM
Data status
Level 1 / 5
AI-parsed

❋ Specs

26
Manufacturer
manufacturer
Martin
1
Lamp type
lamp_type
Philips MSD Platinum 35 2R
1
Lamp power
lamp_power_w
380W
1
Luminous flux
luminous_flux_lm
26000lm
1
Color temperature
color_temperature_k
8000K
1
Pan range
pan_range_deg
540°
1
Tilt range
tilt_range_deg
270°
1
Zoom range
zoom_range_deg
7–56°
1
Color Wheel 1
color_wheel_1
7 dichroic filters + open
1
Color Wheel 2
color_wheel_2
7 dichroic filters + open
1
Cmy Mixing
cmy_mixing
yes
1
Cto Filter
cto_filter
variable CTO (3200–8000 K)
1
Rotating Gobo Wheel
rotating_gobo_wheel
7 rotating + open
1
Gobo Wheel Fixed
gobo_wheel_fixed
7 fixed + open
1
Iris
iris
continuous motorized
1
Frost Filter
frost_filter
variable
1
Strobe rate
strobe_hz
0–20Hz
1
Dimmer
dimmer
0–100% mechanical
1
DMX channels
dmx_channels
48 / 68
1
Protocols
protocols
DMX-512, RDM, Art-Net, sACN
1
Display
display
LCD with control buttons
1
Weight
weight_kg
39.8kg
1
Dimensions
dimensions_mm
489 × 408 × 762 (H in park)mm
1
Housing material
housing_material
die-cast aluminium, polycarbonate cover
1
Cooling
cooling
forced air (fan)
1
Operating temperature
operating_temperature_c
-10 … +45°C
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
