✦Line Arrays

LYON

Manufacturer
Meyer Sound
Model
LYON
Code
GW-4NWVTC
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Configuration
configuration
two-way self-powered linear line array (LYON-M / LYON-W / LYON-WXT)
1
Frequency range
frequency_range_hz
55 - 16500Hz
1
Max SPL
max_spl_db
143.5 (M-noise)dB
1
Drivers
drivers
2x 12-inch long-excursion cone drivers (LF, 4 ohm); 2x 3-inch diaphragm compression drivers on constant-directivity horn via REM manifold (HF, 16 ohm)
1
Amplifier
amplifier
3-channel complementary MOSFET output stages (class AB/H bridged)
1
Power
power_w
8500 peakW
1
Dimensions
dimensions
969 W x 377 H x 533 Dmm
1
Horizontal coverage
horizontal_coverage_deg
90 (LYON-M) / 110 (LYON-W, LYON-WXT)deg
1
Input impedance
input_impedance_ohm
10000 differentialohm
1
Ac Connector
ac_connector
powerCON 32
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
