✦Audio

DL16

Manufacturer
Midas
Model
DL16
Code
GW-WYMOUX
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Mic inputs
mic_inputs
16 (Midas PRO programmable preamps)ch
1
Line Outputs
line_outputs
8 (XLR)ch
1
Sample rate
sample_rate_khz
44.1 / 48kHz
1
Connectivity
connectivity
2x AES50 (SuperMAC), 2x ADAT Toslink, 1x ULTRANET (P-16), MIDI I/O, USB
1
Ad Dynamic Range Db
ad_dynamic_range_db
114 (A-weighted)dB
1
Da Dynamic Range Db
da_dynamic_range_db
120 (A-weighted)dB
1
Frequency range
frequency_range_hz
20-20000 (0 to -1 dB @ 48 kHz)Hz
1
Output Level Dbu
output_level_dbu
+4 nom / +21 maxdBu
1
Latency
latency_ms
1.1ms
1
Power
power_w
45W
1
Dimensions Wxdxh
dimensions_wxdxh_mm
482 x 225 x 89mm
1
Weight
weight_kg
4.7kg
1
Rack units
rack_units_u
2U
1
Connectors
connectors
XLR, AES50 x2, ULTRANET, ADAT Toslink x2, MIDI, USB-B
1
Dimensions
dimensions_mm
482x225x89mm
1
Inputs
inputs
16
1
Outputs
outputs
8
1
Phantom power
phantom_power_v
48V
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
