✦Truss: Straight / Corners

M1200 RTR

Manufacturer
Milos Structural Systems
Model
RTR (M1200 RTR-Truss)
Code
GW-OZJZWF
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Cross section
cross_section_mm
1120 x 1195 (width 800, height 1200 nominal)mm
1
Main Chord Tube
main_chord_tube
60 x 8mm
1
Brace Tube
brace_tube
50 x 4 & 48 x 3mm
1
Alloy
alloy
EN AW-6082 T6
1
Connection type
connection_type
conical connection type R (CCR coupler + PR pin)
1
Max span
max_span_m
50m
1
Udl At 36M Kg Per
udl_at_36m_kg_per_m
120kg/m
1
Center Point Load At 12M
center_point_load_at_12m_kg
8678kg
1
Section Weight 3M
section_weight_3m_kg
77kg
1
Available Lengths
available_lengths
1 / 1.5 / 2 / 2.5 / 3 / 3.5 / 4 / 5m
1
Clamp Compatibility
clamp_compatibility
Cell 300 series (60 mm chord)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
