✦Lighting

Unity RAW 10 FB4

Manufacturer
Pangolin Laser Systems
Model
RAW 10 FB4
Code
GW-SSJINJ
Data status
Level 1 / 5
AI-parsed

❋ Specs

15
Total Optical Power
total_optical_power_w
>10W
1
Power Red
power_red_w
2.7W @ 638 nm
1
Power Green
power_green_w
2.7W @ 525 nm
1
Power Blue
power_blue_w
4.8W @ 455 nm
1
Scan speed
scan_speed_kpps
30Kpps @ 8°
1
Scan angle
scan_angle_deg
50°
1
Beam Size
beam_size_mm
5 x 3mm
1
Beam divergence
beam_divergence_mrad
<1.1mrad (full angle)
1
Modulation
modulation
Analog up to 50 kHz
1
Input voltage (AC)
input_voltage_vac
100-230VAC 50/60 Hz
1
Power
power_w
350W max
1
Weight
weight_kg
12kg
1
Dimensions
dimensions
340 x 247 x 148 (DxWxH)mm
1
Control protocols
control_protocols
FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA out]
1
Price
price_usd
3778USD
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
