✦Lighting

LPC X

Manufacturer
Pharos Architectural Controls
Model
LPC X S3 100
Code
GW-VPQWYC
Data status
Level 1 / 5
AI-parsed

❋ Specs

15
DMX universes
dmx_universes
10-100universes
1
Channel Capacity
channel_capacity
5120-51200channels
1
Protocols
protocols
Art-Net (I/II/3/4 tx), sACN (E1.31), KiNET (V1/V2/V3), Pathport, DMX512
1
Network ports
network_ports
Management + dedicated eDMX etherCON (10/100/1000Base-TX)
1
Video input
video_input
HDMI up to 1080p60 (with HDMI option)
1
Video output
video_output
DisplayPort
1
Audio Io
audio_io
Stereo balanced line-level + SPDIF, LTC timecode input
1
Storage
storage
128GB SSD
1
Real Time Clock
real_time_clock
Battery-backed RTC with astronomical (sunrise/sunset/lunar) functions
1
Form factor
form_factor
19" rack, 1U, 13.5" deep
1
Dimensions
dimensions
483 x 343 x 45 (WxDxH)mm
1
Weight
weight_kg
3.5kg
1
Power
power_w
40 typical / 50 max (100-240V AC, 50-60Hz)W
1
Operating temperature
operating_temperature
0 to 50C
1
Warranty
warranty_years
5years
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
