✦Lighting

TPC

Manufacturer
Pharos Architectural Controls
Model
TPC
Code
GW-2NFKEN
Data status
Level 1 / 5
AI-parsed

❋ Specs

13
Display
display
4.3" capacitive touch panel
1
Resolution
resolution
480 x 272, 24-bit colorpx
1
Brightness
brightness
340cd/m2
1
Channel Capacity
channel_capacity
512channels
1
Protocols
protocols
sACN (E1.31), Art-Net (I/II/3/4 tx), KiNET (V1/V2/V3), Pathport, DMX512
1
Network Port
network_port
RJ45 10/100Base-TX (dual IP for eDMX)
1
Real Time Clock
real_time_clock
Battery-backed RTC with astronomical functions + temperature sensor
1
Mounting
mounting
Wall, recessed in UK 2-gang 35mm or US 2.5" back box
1
Dimensions
dimensions
146 x 86 x 32mm
1
Weight
weight_kg
0.25kg
1
Power
power_w
4 typical (PoE IEEE 802.3af Class 2)W
1
Operating temperature
operating_temperature
0 to 50C
1
Warranty
warranty_years
5years
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
