✦Staging & Structures

Chain Hoist Variable Speed Drive

Manufacturer
Raynok
Model
SN102J
Code
GW-0LHLVP
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Controlled Axes
controlled_axes
1 variable-speed induction or servo
1
Power input
power_input_v
200-230 / 400-480, 3-phaseV
1
Frequency
frequency_hz
50/60Hz
1
Max Input Current
max_input_current_a
8@230V / 4@480VA
1
Encoder Types
encoder_types
TTL, HTL, SIN/COS, SSI Grey Code
1
Load Cell Input
load_cell_input
3mV/V or 4-20mA
1
Motion Controller
motion_controller
1 x SN102J
1
Dimensions
dimensions
300 x 300 x 200 (11"W x 12"H x 8"D)mm
1
Weight
weight_kg
9kg
1
Mounting
mounting
1 point on top with clamp
1
Approvals
approvals
CSA/US Field Evaluation
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
