✦Line Arrays

HDL 26-A

Manufacturer
RCF
Model
13000588
Code
GW-NWUODY
Data status
Level 1 / 5
AI-parsed

❋ Specs

11
Configuration
configuration
2-way active line array module (bi-amped)
1
Weight
weight_kg
13.5kg
1
Dimensions
dimensions
237 x 470 x 377mm
1
Max SPL
max_spl_db
133dB
1
Frequency range
frequency_range_hz
55 - 20000Hz
1
Drivers
drivers
2 x 6.0" neodymium woofers (2.0" voice coil); 1 x 1.5" compression driver (3.0" titanium diaphragm, RCF ND840)
1
Power
power_w
2000 peak / 1000 RMSW
1
Amplifier
amplifier
Class-D
1
Crossover frequency
crossover_hz
750Hz
1
Dispersion
dispersion_deg
100 (H) x 10 (V)degrees
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
