✦Line Arrays

HDL 30-A

Manufacturer
RCF
Model
STP0691
Code
GW-76XVWD
Data status
Level 1 / 5
AI-parsed

❋ Specs

14
Configuration
configuration
2-way active (bi-amped)
1
Frequency range
frequency_range_hz
50 - 20000Hz
1
Max SPL
max_spl_db
137dB
1
Drivers
drivers
2 x 10'' neo woofer (2.5'' v.c) + 1 x 1.4'' neo compression driver (4.0'' v.c)
1
Power
power_w
2200 peak / 1100 RMSW
1
Amplifier
amplifier
Class-D
1
Crossover frequency
crossover_hz
680Hz
1
Horizontal coverage
horizontal_coverage_deg
100°
1
Vertical coverage
vertical_coverage_deg
15°
1
DSP
dsp
48 kHz, 32-bit
1
Weight
weight_kg
25kg
1
Dimensions
dimensions
293 x 705 x 502 (H x W x D)mm
1
Cabinet material
cabinet_material
PP Composite
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
