✦Line Arrays

HDL 50-A

Manufacturer
RCF
Model
HDL 50-A
Code
GW-JLBIED
Data status
Level 1 / 5
AI-parsed

❋ Specs

18
Type
type
active (self-powered)
1
Configuration
configuration
2-way (biamp)
1
LF drivers
lf_drivers
2 × 10"дюйм
1
HF driver
hf_driver
1 × compression driver with waveguide
1
Amplifier class
amplifier_class
class D
1
Power
power_w
1400Вт (пиковая)
1
RMS power
power_rms_w
700Вт (RMS)
1
Frequency range
frequency_range_hz
65 – 20 000Гц
1
Max SPL
max_spl_db
139дБ (пиковый SPL)
1
Dispersion H Deg
dispersion_h_deg
100°
1
Dispersion V Deg
dispersion_v_deg
10°
1
Weight
weight_kg
29кг
1
Dimensions
dimensions_mm
700 × 310 × 400мм (Ш × Г × В)
1
Enclosure material
enclosure_material
multi-layer plywood + plastic overlays
1
Connector type
connector_type
speakON / XLR (AES/EBU)
1
DSP
dsp
built-in DSP with factory presets
1
Rigging
rigging
integrated mechanical coupling system for vertical array
1
Amplification
amplification
Self-powered (built-in amplifier)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers

Self-powered (built-in amplifier)
