✦Moving Head (Spot/Wash/Beam)

BMFL Blade

Manufacturer
Robe Lighting
Model
BMFL Blade
Code
GW-KPPJHJ
Data status
Level 1 / 5
AI-parsed

❋ Specs

43
Manufacturer
manufacturer
Robe
1
Model Family
model_family
BMFL
1
Light source
light_source
Discharge lamp — Osram Sirius HRI 1700W
1
Power
power_w
2100W
1
Luminous flux
luminous_flux_lm
126000lm
1
Color temperature
color_temperature_k
6000K
1
Beam angle
beam_angle_deg
0–53°
1
Framing Blades
framing_blades
4 independent blades with frame rotation ±60°
1
Pan range
pan_range_deg
540°
1
Tilt range
tilt_range_deg
268°
1
Weight
weight_kg
54.5kg
1
Dimensions
dimensions_mm
530 × 390 × 790 (L × W × H)mm
1
Color Wheels
color_wheels
2 (1× fixed colors + 1× CMY-compatible)
1
Cmy Mixing
cmy_mixing
Yes — full CMY color mixing
1
Cto Filter
cto_filter
Yes — linear CTO
1
Rotating gobos
rotating_gobos
7 + open
1
Static gobos
static_gobos
9 + open
1
Prism
prism
1× 6-facet rotating prism
1
Iris
iris
Yes — mechanical iris
1
Frost Filter
frost_filter
Yes — linear
1
Strobe
strobe
Yes — mechanical strobe
1
Dimmer
dimmer
Mechanical, 0–100%
1
Zoom Type
zoom_type
Motorized
1
Focus Type
focus_type
Motorized
1
Control protocol
control_protocol
DMX-512 / RDM
1
DMX channels
dmx_channels
3 modes (Standard / Extended / Basic)
1
DMX channels
dmx_channels
40 / 38 / 16
1
Display
display
OLED + encoders
1
Cooling
cooling
Forced air cooling (fans)
1
DMX connector
dmx_connector
3-pin & 5-pin XLR
1
Power connector
power_connector
PowerCon TRUE1
1
Control
control
USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN (CRMX wireless on request)
1
CRI
cri
92+
1
Heat Dissipation Btu H
heat_dissipation_btu_h
5800 (max, calculated)BTU/h
1
Illuminance
illuminance_lx
250000 @ 5 m; 2500 @ 50 mlx
1
Input voltage
input_voltage_v
200-240 (50/60 Hz)V
1
IP rating
ip_rating · safety-critical
IP20
1
Lamp Lifetime H
lamp_lifetime_h
750 (at 1700/1500 W / Quiet mode)h
1
Max Ambient Temperature C
max_ambient_temperature_c
45°C
1
Pan
pan_deg
540°
1
Power consumption
power_consumption_w
2000 (at 230 V / 50 Hz)W
1
Tilt
tilt_deg
270°
1
Zoom range
zoom_range_deg
5-55 (ratio 11:1)°
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
