✦Moving Head (Spot/Wash/Beam)

BMFL WashBeam

Manufacturer
Robe Lighting
Model
BMFL WashBeam
Code
GW-E4EJGR
Data status
Level 1 / 5
AI-parsed

❋ Specs

22
Light source
light_source
OSRAM Lok-it! HTI 1700/PS (compact short-arc metal halide, PGJX28 base)
1
Power
power_w
2000W
1
Lamp power
lamp_power_w
1700W
1
Input Voltage Range
input_voltage_range
200-240V
1
Input Frequency Hz
input_frequency_hz
50/60Hz
1
Luminous flux
luminous_flux_lm
41000lm
1
Illuminance
illuminance_lx
300000 @ 5 m; 3000 @ 50 mlx
1
Color temperature
color_temperature_k
6000K
1
CRI
cri
92+
1
Zoom range
zoom_range_deg
5-45°
1
Front Lens Diameter
front_lens_diameter_mm
180mm
1
Pan
pan_deg
540°
1
Tilt
tilt_deg
270°
1
Weight
weight_kg
38.4kg
1
Dimensions
dimensions
826 (H) x 483 (W) x 335 (D)mm
1
Max Ambient Temperature C
max_ambient_temperature_c
45°C
1
Heat Dissipation Btu H
heat_dissipation_btu_h
5800BTU/h
1
Drivers
drivers
CMY + variable CTO, 2 colour wheels, framing shutters (4 blades + frame rotation ±45°), rotating gobo wheel (6 gobos), animation wheel, iris, variable frost, motorised zoom/focus, EMS stabilisation
1
Protocols
protocols
USITT DMX-512, RDM, Art-Net, MA Net/MA Net2, sACN
1
DMX channels
dmx_channels
48 / 41 (2 modes)
1
Power connector
power_connector
Neutrik powerCON
1
Data Connectors
data_connectors
3-pin & 5-pin XLR (DMX/RDM), RJ45 (Ethernet)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
