✦PAR / LED / Profile

ESPRITE

Manufacturer
Robe Lighting
Model
ESPRITE
Code
GW-TEDUXC
Data status
Level 1 / 5
AI-parsed

❋ Specs

29
Weight
weight_kg
28.2kg
1
Dimensions
dimensions
733 x 443 x 264mm
1
Light source
light_source
TE 650W transferable white LED engine (HP/HCF/TGW)
1
Power
power_w
870 (standard) / 950 (high-power) @ 230VW
1
Luminous flux
luminous_flux_lm
34000lm
1
Illuminance
illuminance
85000 @ 5 mlx
1
Color temperature
color_temperature_k
6700K
1
CRI
cri
70 (HP, retractable CRI 80/90 filters)
1
Zoom range
zoom_range_deg
5.5 - 50deg
1
Zoom ratio
zoom_ratio
9:1 (13-lens optical system)
1
Front Lens Diameter
front_lens_diameter_mm
150mm
1
Color mixing
color_mixing
CMY + variable CTO (3000-6700K) + ChromaTint green correction
1
Color Wheels
color_wheels
2 wheels, each 5 dichroic colors + white
1
Rotating gobos
rotating_gobos
7 rotating, indexable, replaceable + open (SLOT&LOCK)
1
Static gobos
static_gobos
9 static, replaceable + open
1
Prism
prism
6-facet, rotating both directions
1
Framing Shutters
framing_shutters
Plano4 module, 4 individually positionable blades, full frame rotation +/-60
1
Iris
iris
motorized, continuous, pulse effects up to 3 Hz
1
Frost
frost
MagFrost magnetic swappable (1 deg + 5 deg standard)
1
Strobe rate
strobe_hz
up to 20Hz
1
Pan
pan_deg
540deg
1
Tilt
tilt_deg
265deg
1
DMX channels
dmx_channels
49 / 42 / 50 / 43 (4 DMX modes)
1
Control protocols
control_protocols
USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN
1
Power connector
power_connector
Neutrik powerCON TRUE1
1
Data Connectors
data_connectors
3-pin & 5-pin locking XLR in/out, RJ45
1
Noise
noise_db
27 dB(A) quiet / 42 dB(A) auto @ 1 mdB(A)
1
LED life
led_life_hours
min 50000 (L70/B50)h
1
Approvals
approvals
CE, cETLus
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
