✦Power

ComPact NSX

Manufacturer
Schneider Electric
Model
NSX630N
Code
GW-UI87G1
Data status
Level 1 / 5
AI-parsed

❋ Specs

9
Rated Current Range
rated_current_range_a
16-630A
1
Rated voltage
rated_voltage_v
690V
1
Rated Insulation Voltage
rated_insulation_voltage_v
800V
1
Breaking Capacity Ka
breaking_capacity_ka
up to 150 (at 415V)kA
1
Frequency
frequency_hz
50/60Hz
1
Poles
poles
3P / 4Ppole
1
Frame Sizes
frame_sizes
2 (NSX100-250, NSX400-630)
1
Trip Unit
trip_unit
thermal-magnetic / MicroLogic
1
Standard
standard
IEC 60947-2
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
