✦Line Arrays

GL 24

Manufacturer
Seeburg acoustic line
Model
00520/dp
Code
GW-JIBRTY
Data status
Level 1 / 5
AI-parsed

❋ Specs

10
Drivers
drivers
6 x 6.5" Nd / 24 x 1" Nd tweeter
1
Power
power_w
2 x 800W AES (dp, biamped)
1
Max SPL
max_spl_db
130dB peak @ 1m
1
Frequency range
frequency_range_hz
80 - 20000Hz (-6 dB)
1
Dispersion
dispersion_deg
100 x 20deg (H x V)
1
Impedance
impedance_ohm
5.3Ohm
1
Weight
weight_kg
22kg
1
Dimensions
dimensions
106.0 x 18.9 x 34.3cm (H x W x D)
1
Connectors
connectors
XLR in/thru, Ethercon, Powercon in/thru, Speakon NL4MP out
1
DSP
dsp
DPLMx FPGA 32 bit floating point, 24 bit / 96 kHz
1
