✦Wired Microphones

017 Tube

Manufacturer
Soyuz Microphones
Model
SU-017
Code
GW-D1WZYS
Data status
Level 1 / 5
AI-parsed

❋ Specs

12
Type
type
tube condenser
1
Polar pattern
polar_pattern
cardioid
1
Diaphragm
diaphragm_mm
34mm
1
Frequency range
frequency_range_hz
20-20000Hz
1
Sensitivity
sensitivity_mv_pa
40mV/Pa
1
Output impedance
output_impedance_ohm
270Ohm
1
Max SPL
max_spl_db
140dB
1
Self-noise
self_noise_dba
20dB(A)
1
Tube Type
tube_type
6ZH1P
1
Power
power_w
dedicated power supply BP-017
1
Dimensions
dimensions
226 length x 55 diametermm
1
Weight
weight_g
950g
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
