✦Power Distros

C72tv

Manufacturer
StageSmarts
Model
C72tv
Code
GW-HIY095
Data status
Level 1 / 5
AI-parsed

❋ Specs

9
DMX channels
dmx_channels
72
1
Channel Current
channel_current_a
16A
1
Rcbo Type
rcbo_type
A-type, 30mA
1
Input connector
input_connector
Powerlock 400A 5-wire (TN-S), optional 750A
1
Input current
input_current_a
400A
1
Main Breaker
main_breaker
4-pole 400A MCCB electronic
1
Aux Outputs
aux_outputs
6x 1-phase (16/32A) + 3x 3-phase (16-63A)
1
Weight
weight_kg
150kg
1
Dimensions
dimensions
1342 x 600 x 723 (wheeled flightcase)mm
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
